Products Description
The two-wire radar water level meter is an instrument that uses the principle of radar waves to measure water levels. It consists of an antenna, a transmitter-receiver and a processor. The antenna transmits radar waves to the liquid surface, which are reflected by the liquid surface and returned to the receiver, and then the liquid surface distance is calculated to achieve the purpose of measuring the water level. The two-wire radar water level meter has the advantages of low energy consumption, easy maintenance, high measurement accuracy and strong adaptability. It is suitable for various water level measurement occasions, such as reservoirs, rivers, hydrological stations, water treatment stations, etc. It is easy to operate, and can perform automatic measurement after simple settings. It can also realize data transmission through 4-20mA, which is convenient for real-time monitoring of water level changes. In addition, the two-wire radar water level meter also has strong anti-interference ability and adaptability. It can operate in various harsh environments, such as rain, snow, oil mist, strong electromagnetic fields, etc. It can still work stably, so it has been widely used.
Technical Parameters
| Features | Multiple antennas, anti-condensation and anti-hanging; | Process temperature | -40～100°C |
| Application | It is widely used in the measurement of various liquid levels. Such as: oil tanks, pools, etc. | Process pressure | -0.1～0.3MPa |
| Maximum range | 80m | Frequency range | 80GHz |
| Measurement accuracy | ±3mm | Signal output | 4～20mA |
| Antenna material | PTFE | Power supply | DC9-36V |
 |
|
